Biometra Fastblot - The standard for qualitative and quantitative protein analysis
- Fast and homogeneous transfer of proteins
- Maximum transfer efficiency
- Easy and fast setup
Product Details
Biometra Fastblot – Rapid and Efficient Blotting
Electro-blotting is a standard method to transfer proteins and nucleic acids from polyacrylamide gels to nitrocellulose or other carrier membranes. To enable you to achieve high-quality, publishable results with minimal effort, we at Analytik Jena have developed powerful Western Blot systems that are ideally suited to your needs.
Experience a new level of quality in terms of reproducible qualitative and quantitative protein analysis and reduce your transfer time to a minimum! The Biometra Semidry Blotter is equipped with high-quality plate electrodes made of titanium-coated platinum and stainless steel which create a homogeneous stress field that ensures a fast and homogeneous transfer of biomolecules to a carrier membrane. At the same time a uniform temperature distribution over the entire transfer area is guaranteed.
Heterogeneous protein mixtures with very different molecular weights or native proteins represents a special challenge. With the cooling option of the Fastblot B43 (connections for cooling water at the anode), excess heat can be dissipated efficiently and enables a reliable and gentle transfer of challenging samples even at high current levels.
- Compact design and low buffer requirement
- Corrosion-resistant plate electrodes made of platinum coated titanium and stainless steel
- Realization of faster transfer times through effective cooling
Technical Data
| Rapid Semi-Dry Transfer | ||
|---|---|---|
| Fastblot B43 | Fastblot B44 | |
| Electrode | Cathode: Stainless steel Anode: Platinum-coated titanium | Cathode: Stainless steel Anode: Platinum-coated titanium |
| Transfer time | 10 - 30 min | 10 - 30 min |
| Capacity of device | 2 mini gels or 1 midi gel | 2 mini gels or 1 midi gel |
| Blotting area (W x D) | 16.0 x 20.0 cm | 16.0 x 20.0 cm |
| Transfer buffer requirement | < 200 ml | < 200 ml |
| Cooling option | Yes | No |
| Max. flow rate | 0.5 - 1 l/min | - |
| Dimensions (W x D x H) | 26.0 x 22.0 x 11.0 cm | 24.0 x 22.0 x 11.0 cm |
| Electrode distance | Determined by sandwich thickness | Determined by sandwich thickness |
| Max. Voltage | 50 V | 50 V |
| Max. Current | 5 mA/cm² | 5 mA/cm² |
| Max. Power | 10 W (30 W for 30 min when cooled to 12 °C) | 10 W (20 W for 30 min) |
| Max. Operation Temperature | 50 °C | 50 °C |
| Weight | 2.5 kg | 2.5 kg |
| Power supply | P25/P25T | P25/P25T |
Order Information
Biometra Fastblot
| Order number | Item |
|---|---|
| 846-015-100 | Fastblot B43, anode: platinum-coated titanium, cathode: stainless steel, with flow-through cooling |
| 846-015-200 | Fastblot B44, anode: platinum-coated titanium, cathode: stainless steel, without cooling |
Accessories
| Order number | Accessories |
|---|---|
| 846-B3030931 | Whatman 3MM Chr, 580 mm x 680 mm, 0.34 mm thick, 100/pkg |
| 846-B3017915* | Whatman 17Chr, 460 mm x 570 mm, 0.92 mm thick, 25/pkg |
| 846-B10426981* | Whatman GB005, 200 mm x 200 mm, 1.5 mm thick, 25/pkg |
Accessoires Biometra Vacu-Blot**
Order number | Item |
|---|---|
| 846-053-002 | Rubber sheets (280 mm x 280 mm) for Vacu-Blot, 3 pieces |
| 846-053-004 | Porous filter plate for Vacu-Blot |
| 846-010-057 | Clips (1 set), 6 pieces |
| * Please note that the product is discontinued. A sale is only possible while stocks last. **Vacu-Blot is discontinued. Accessories are yet available. | |
Order information on suitable power supplies and adapters can be found here.
