Protran Blotting Membranes

Protran Blotting Membranes

Standard membranes for protein and nucleic acid blotting

Product Details

  • Standard membranes for protein and nucleic acid blotting
  • Excellent sensitivity, resolution and low background
  • Superior mechanical strength
  • Compatible with a variety of assays and detection methods
ProtranPortran
supported
  • Best and easiest blocking of unspecific binding compared to all blotting membranes
  • Superior for chemiluminescence detection using horseradish peroxidase based systems
  • Unsupported, 100 % pure nitrocellulose membrane
  • Reinforced nitrocellulose membranes
  • Allows multiple reprobings without loss of membrane integrity
  • Excellent signal-to-noise ratio

Protran® nitrocellulose membranes are the most frequently specified transfer media in the world for Western, Southern and Northern blotting. Additionally, the membrane is excellent for carbohydrate studies (Glycomics).

Protran membranes are manufactured using 100 % pure nitrocellulose to ensure the highest binding capacity possible. Other membranes referred to as “nitrocellulose“ may actually contain large amounts of cellulose acetate which will lower the protein binding capacity.

Protran® membranes have the best handling strength of all pure nitrocellulose membranes. They are compatible with a variety of detection methods, including isotopic, chemiluminescent (peroxidase/ luminol-based), colorimetric and fluorescent. Unlike PVDF membranes, Protran nitrocellulose requires no methanol pre-wetting step. This makes it the membrane of choice for proteins which prefer aqueous environments. Prior to transfer, the membrane is simply wet in water, and then in the transfer buffer. No other pre-treatment steps are necessary.

High binding capacity
The 0.20 μm pore size of the Protran (NC 0.2) nitrocellulose membrane ensures high binding capacity of small samples below 20 kD by reducing “blow-through“. The 0.45 μm pore size membrane (NC 0.45) is ideal for larger molecular weight samples.

Low background
In addition to the high binding capacity, Protran nitrocellulose membranes inherently have very low background. The superior surface properties of the membrane guarantee superior signal-to-noise ratios, without the need for stringent washing conditions.

Protein stability for years
A particular benefit of the proprietary Protran nitrocellulose formula is the proven excellent shelf life of proteins. Empirical evidence shows that proteins maintain molecular recognition activity for five years on Protran, which makes it the standard for protein blotting.

The Protran supported membrane consists of pure 100 % nitrocellulose cast onto both sides of an inert polyester support material. The support in no way affects transfer conditions or results and gives the membrane exceptional handling characteristics, allowing it to be reprobed repeatedly.

The Protran supported nitrocellulose membrane provides high sensitivity with very low non-specific binding without stringent washing and blocking conditions using standard nitrocellulose protocols.

The combination of flexibility, strength and excellent signal-to-noise ratios makes the Protran supported membrane ideal, especially when procedures involve repeated stripping and reprobing.

Protran supported nitrocellulose membranes combine sensitivity, strength and savings.

Technical Data



Protran®

Protran
supported®

Membrane type

Nitrocellulose, 100 % pure

Nitrocellulose, reinforced

Binding capacity

80 – 90 μg/cm2

Approx. 60 – 80 μg/cm2

Pore sizes

0.45 μm
0.20 μm

0.45 μm

Transfer methods

Semi-dry blotting

++

++

Tank blotting

++

++

Vacuum blotting

++

++

Capillary blotting

++

++

Immobilization techniques

Drying

Proteins

Proteins

UV-crosslinking

DNA and RNA

DNA and RNA

Backen (80 °C)

DNA und RNA

DNA und RNA

Detection methods

Colorimetric

++

++

Chemiluminescent*

++

++

Isotopic

++

++

Fluorescent

Proteins

Reprobing

+

++

++ = recommended
+   = limited use
–   = not recommended
* Use of horseradish peroxidase based systems is recommended.

Order Information

Order numberItemPore sizeDimensionQuantity/ Pack
846-B10401396*Protran NC 0.20.20 µm30 cm x 4 m1 roll
846-B10401196*Protran NC 0.450.45 µm30 cm x 4 m1 roll
846-B10401180*Protran NC 0.450.45 µm30 cm x 60 cm5 sheets/pack

846-B10402580*

Protran NC 0.450.45 µm33 cm x 56 cm5 sheets/pack

846-B10439196*Protran supported NC 0.450.45 µm30 cm x 4 m1 roll

* Please note that the product is discontinued. A sale is only possible while stocks last.
